LEO Earth Observation
X-band bulk downlink with burst scheduling support. High-inclination orbital coverage, multi-aperture handoffs for extended contact windows, and priority queue access for time-sensitive imagery products.
Learn moreGround Station Network · El Segundo CA
Your Spacecraft.
Our Antennas.
Any Orbit.
Orbitvein connects LEO and MEO operators to a managed network of S-, X-, and Ka-band ground stations. No infrastructure. No long-term contracts. First contact scheduled in under 48 hours.
S / X / Ka
3 Frequency Bands
3.7m – 9m
Antenna Aperture Range
<0.1 mdeg
Autotrack Precision
CCSDS
Packet Capture Ready
How It Works
From TLE to Telemetry in Three Steps
STEP 01
Ingest Your TLE
Submit your NORAD catalog ID or TLE set via the API or contact form. Our propagation engine computes pass predictions for the next 7 days across all available stations, accounting for minimum elevation masks and frequency band availability.
STEP 02
Schedule a Contact Window
Select an AOS/LOS time slot, preferred aperture size, and frequency band. The scheduler performs real-time conflict checking across all active reservations and confirms your contact window — typically within minutes.
STEP 03
Receive Your Data
CCSDS-framed packet capture is delivered to your designated cloud endpoint immediately post-contact. Telemetry logs, Doppler tracking data, and contact reports are available via the API within minutes of LOS.
The Network
Precision Infrastructure.
Precision Infrastructure.
No Compromise.
| Aperture | G/T (dB/K) | EIRP (dBW) | Bands | Tracking |
|---|---|---|---|---|
| 3.7 m | 18.5 | 52 | S, X | 0.08 mdeg |
| 5.4 m | 22.1 | 58 | S, X | 0.06 mdeg |
| 7.3 m | 26.4 | 64 | X, Ka | 0.05 mdeg |
| 9.0 m | 29.8 | 68 | X, Ka | 0.04 mdeg |
Geographic Distribution
Four operational stations span the Pacific Rim, North Atlantic, Mid-continent, and Southern hemisphere access zones. Station positioning is optimized for high-inclination LEO pass geometry, providing overlapping coverage windows for polar, sun-synchronous, and near-polar operators.
Each station operates 24/7 with scheduled maintenance windows disclosed at least 72 hours in advance. Contact redundancy routing is available for Constellation tier and above — if your primary station has a scheduling conflict, the system automatically offers an alternate window at the nearest compatible site.
All stations support CCSDS TC and TM framing, virtual channel multiplexing (up to 8 VCIDs per physical link), and full Doppler pre-compensation from AOS to LOS. We are not a satellite broadband provider — this infrastructure is built specifically for spacecraft operators who need reliable, schedulable antenna access.
Coverage
Global Coverage for LEO Passes
4 – 8
Avg passes/day
per spacecraft
per spacecraft
89°
Max contact
elevation angle
elevation angle
5°
Min elevation
mask
mask
Built for Operators
Every Mission Type. One Integration.
IoT Constellations
S-band bi-directional TT&C at scale. API-driven uplink command sequencing for multi-spacecraft planes, low-latency confirmation, and scheduling optimized for high plane-count operations.
Learn moreCubeSat & Research
Per-pass pricing with no minimum commitment. NORAD ID onboarding within 24 hours. Flexible contact windows for university programs, early-mission validation, and experimental payloads.
Learn more
Pricing
Transparent Per-Pass Pricing
No hidden fees. No lock-in. Pay for the contacts you use.
Mission Starter
$89
/ contact
Up to 5 contacts/month · S or X band · 3.7m aperture · 10-min max
- Best-effort scheduling
- CCSDS TM delivery
- API access included
Recommended for LEO EO
Constellation
$198
/ contact
10 contacts/month bundle ($1,980/mo) · X and Ka band · Up to 7.3m
- Priority scheduling queue
- Multi-spacecraft discounting
- Contact redundancy routing
Custom Network
Custom
10+ spacecraft · Custom SLAs · Dedicated windows · Full API integration
- Dedicated station time windows
- Custom SLA terms
- API integration support
Your First Contact in Under 48 Hours
Send us your NORAD ID and preferred frequency band. We handle the rest.
